| Place of Origin: | CHINA |
|---|---|
| Brand Name: | KINTE |
| Certification: | ROHS,ISO90001,ISO14000,Reach,Qualicoat |
| Model Number: | NH3386 |
| Minimum Order Quantity: | 500KG |
| Price: | Negotiable |
| Packaging Details: | 25kg/PE bag , 875KG/PALLET , 17,500KG/ 20GP |
| Delivery Time: | 10 working days |
| Payment Terms: | T/T, L/C, D/P |
| Supply Ability: | 80,000tons/year |
| Specification: | TGIC Cure | Application: | Powder Coating Manufacture For Outdoor Use |
|---|---|---|---|
| Advantage: | Excellent Flowability,heat Resistance&anti-yellowing | Property: | Outstanding Mechanical Property&storage Stability |
| Curing Condition: | 200°C/10mins | ||
| High Light: | Good Flow TGIC powder coating,93:7 TGIC powder coating,93:7 polyester resin tgic agent |
||
Polyester Resin for General Industrial Powder Coating
◇ Applications:
NH3386 is saturated carboxyl polyester resin for applications of polyester/TGIC
powder coating system.
◇ Basic features:
Good flowability
Outstanding mechanical properties
Excellent of heat resistance and excellent anti-yellowing
Excellent storage stability
◇ Specifications:
Appearance pale yellow flake
Color(50%DMF): max:2
Acid number(mgKOH/g): 31～36
Softening point(℃): 105～115
Glass transition temp.(℃): ～69
Melting viscosity(200℃, cone/plate, mPa·s): 6500±1500
Reactivity at 180℃(s, 7% TGIC): 170～250
◇ Recommend Formulation:
| NH3386 | TGIC | Filler ＆ pigment | Leveling agent | Benzion |
| 200 | 15 | 140 | 2.4 | 1.2 |
◇ Extrusion Condition:
Two-screw extruder
Zone I: 90～110℃ Zone II: 110～120℃
Speed of revolution: 500～1200rpm
Fineness of powder: ＜100μm
◇ Application Condition:
Electrostatic spraying with: 40～70KV
Coating film thickness: 50～100μm
Degreased cold-rolled steel 0.5mm
◇ Curing Requirement: 200℃×10min
◇ Film Properties:
Gel time(180℃,sec): 260~360
Flow(180℃,mm) :23~28
Gloss(60°):≥85%
Bending(φ1mm): pass
Adhesive(1mm,grade): 0
Pencil hardness: 1H
Impact(50cm): pass
Storage test(40℃,24hr): good
Remarks:all the polyester resins could be customizes to Non-tin (A) ,anti gas burners(G),tribo gun(T) and anti-blooming(F)
