| Place of Origin: | CHINA |
|---|---|
| Brand Name: | KINTE |
| Certification: | Qualicoat,ISO90001,ISO14000,Reach |
| Model Number: | NH3005 |
| Minimum Order Quantity: | 500KG |
| Price: | Negotiable |
| Packaging Details: | 25kg/PE bag , 875KG/PALLET , 17,500KG/ 20GP container |
| Delivery Time: | 10 working days |
| Payment Terms: | T/T, L/C, D/P |
| Supply Ability: | 80,000tons/year |
| Specification: | TGIC Cure | Application: | Thermal Transfer Print Powder Coating For Outdoor Use |
|---|---|---|---|
| Advantage: | Excellent In Thermal Transfer Print And With Very Good Weather Ability | Property: | Smooth And High Gloss |
| Ratio: | 90/10 | Curing: | 200°C/10mins |
| High Light: | TGIC powder coating polyester resin,90/10 powder coating polyester resin,90/10 TGIC polyester powder coating |
||
Saturated Polyester Resin in 90/10 TGIC Cure NH3005 for High Gloss and Durable Powder Coating
◇ Applications:
NH3005 is a saturated carboxyl polyester resin for applications of polyester/TGIC powder coating system at the ratio 90/10.
◇ Basic features:
Excellent leveling
Good mechanical properties
Suitable for heat transfer printing powder coatings
◇ Specifications:
Appearance white or light yellow transparent flakes
Color(50%DMF): max:3
Acid number(mgKOH/g): 50～55
Softening point(℃) 103～113
Glass transition temp.( ℃) ～64
Melting viscosity(200℃, cone/plate, mPa·s): 2200±500
Reactivity at 180℃(s, 10% TGIC) 220±60
◇ Recommend Formulation:NH3005—TGIC
| NH3005 | TGIC | Filler ＆ pigment | Leveling agent | Benzoin | 701 |
| 540 | 60 | 383 | 8 | 4 | 5 |
◇ Extrusion Condition:
Two-screw extruder
Zone I: 90～110℃ Zone II: 110～120℃
Speed of revolution: 500～1200rpm
Fineness of powder: ＜100μm
◇ Application Condition:
Coating film thickness: 50～100μm
Degreased cold-rolled steel 0.5mm
◇ Curing Requirement: 200℃×10min
◇ Film Properties:
Gel time(180℃, sec) 240~360
Horizontal flow(180℃, mm): 26-31
Gloss (60°): 85% min
Bending(φ1mm): pass
Adhesive(1mm,grade): 0
Pencil hardness: 1H
Impact(direct,reserve): pass 50kg·cm
◇ Packaging:
PE bags, N.W. 25KG±0.1KG / bag
Remarks:all the polyester resins could be customizes to Non-tin (A) ,anti gas burners(G),tribo gun(T) and anti-blooming(F)
Kinte Material Technology Co., Ltd. is a state-owned holding enterprise specializing in the R & D, production and sales of powder coatings, saturated polyester resin for powder coatings, liquid coatings and special new materials.
