Place of Origin: | CHINA |
---|---|
Brand Name: | KINTE |
Certification: | ROHS,ISO90001,ISO14000,Reach,Qualicoat |
Model Number: | NH7405&NH7803 |
Minimum Order Quantity: | 500KG |
Price: | Negotiable |
Packaging Details: | 25kg/PE bag , 875KG/PALLET , 17,500KG/20GP |
Delivery Time: | 10 working days |
Payment Terms: | T/T, L/C, D/P |
Supply Ability: | 80,000 tons/year |
Specification: | Isocyanate | Application: | Matte Or Low Gloss Powder Coating |
---|---|---|---|
Advantage: | Good Film Appearance | Rate: | 40/60,80/20 |
Curing Condition: | 200°C/15mins | Property: | Excellent Resistance To Chemical,outstanding Durable Weatherablity |
Highlight: | 15mins cure Isocyanate polyester Resin,saturated Isocyanate polyester Resin,Isocyanate polyester based resin |
Super Durable Isocyanate Polyester Resin NH7405&NH7803 One-time Extrusion for Matte PU Powder Coating
◇ Applications:
NH7405/NH7803 are saturated carboxyl polyester resins for low gloss or matte polyester/isocyanate powder coatings by one shot extrusion.
◇ Basic features:
Excellent weathering resistance
Good chemical resistance
Good film appearance
Suitable for matt or low gloss powder coating
◇ Specifications:
NH7405 NH7803
Appearance pale yellow flake pale yellow flake
Color(50%DMF): ≤2 ≤2
Hydroxyl Valu((mgKOH/g): 280~320 35~45
Softening point(℃): 102~112 102~112
Glass transition temp.( ℃): ~55 ~57
Melting viscosity: 3000~5000 3000~5000
(200℃, cone/plate, mPa·s)
Reactivity at 180℃(s, B1530): 120~240 300~420
◇ Recommend Formulation:
NH7405 | NH7803 | B1530 | TiO2 | BaSO4 | Leveling agent | Benzoin |
137 | 205 | 257 | 205 | 183 | 10 | 3 |
◇ Extrusion Condition:
Two-screw extruder
Zone I: 90~110℃ Zone II: 110~120℃
Speed of revolution: 500~1200rpm
Fineness of powder: <100μm
◇ Application Condition:
Electrostatic spraying with: 40~70KV
Coating film thickness: 50~80μm
Degreased cold-rolled steel 0.5mm
◇ Curing Requirement: 200℃×15min
◇ Film Properties:
Gloss(60°): ≤20%
Pencil hardness: ≥ 3H
◇ Packaging:PE bags, N.W. 25KG±0.1KG / bag
Remarks:all the polyester resins could be customizes to Non-tin (A) ,anti gas burners(G),tribo gun(T) and anti-blooming(F)
