ISO90001 Blended Polyester Resin , Powder Paint Polyester Resin 25Kg For Heat Transfer

Basic Information
Place of Origin: CHINA
Brand Name: KINTE
Certification: ROHS,ISO90001,ISO14000,Reach,Qualicoat
Model Number: NH8003&NH8606
Minimum Order Quantity: 500KG
Price: Negotiable
Packaging Details: 25kg/PE bag , 875KG/PALLET , 17,500KG/20GP
Delivery Time: 10 working days
Payment Terms: T/T, L/C, D/P
Supply Ability: 80,000tons/year
Specification: TGIC Cure Application: Powder Coating With Low Gloss Heat Transfer Finish
Advantage: Good Leveling Property: Good Mechanical Property,chemical Resistance,weatherability,storage Stability
Ratio: 90/10,95/5 Curing Condition: 200°C/10mins
Highlight:

25Kg Blended Polyester Resin

,

ISO90001 Blended Polyester Resin

,

ISO90001 Powder Paint Polyester resin



Powder Paint Polyester resin NH8003&NH8606 for Low Gloss Heat Transfer Finish



◇ Applications:

NH8003/NH8606 are saturated carboxyl polyester resins for low gloss polyester/TGIC powder coatings by a dry blend procedure.



Compared with the products of other manufacturers, the curing degree of our powder coating film is also higher, and the transfer paper tearing performance of the film is better. It is more suitable for the preparation of hybrid polyester for heat transfer powder coating.



◇ Basic features:

Good leveling

Excellent mechanical properties

Good weathering resistance



◇ Specifications:

                                                        NH8003                                NH8606



Appearance:                             pale yellow flake                  pale yellow flake



Color(50%DMF):                                 ≤3                                          ≤3



Acid number(mgKOH/g):                 48~54                                  19~24



Softening point(℃):                        108~118                              103~113



Glass transition temp.( ℃):                  ~68                                        ~60



Melting viscosity:                         5000±1000                             9000±1000

(200℃, cone/plate, mPa·s)



Reactivity at 180℃ :                      80±30                                     340±60

(s, 10, 4% TGIC)



◇ Recommend Formulation:

Formulation NH8003 NH8606 TGIC Filler & pigment Leveling agent Benzion
I 270 30 200 3 1.5
II 288 12 200 3 1.5



◇ Extrusion Condition:

Two-screw extruder

Zone I: 90~110℃ Zone II: 110~120℃

Speed of revolution: 500~1200rpm

Fineness of powder: <100μm

Blending Extrude I and II with weight ratio 1:1 before grinding.



◇ Application Condition:

Electrostatic spraying with: 40~70KV

Coating film thickness: 50~80μm

Degreased cold-rolled steel 0.5mm



◇ Curing Requirement: 200℃×10min



◇ Film Properties:

Gloss(60°): ≤35%

Bending(φ2mm): Pass

Adhesive(1mm,grade): 0

Pencil hardness: 1H

Direct Impact (50cm): pass



Packaging:

PE bags, N.W. 25KG±0.1KG / bag



Remarks:all the polyester resins could be customizes to Non-tin (A) ,anti gas burners(G),tribo gun(T) and anti-blooming(F)



We will continue to uphold the business philosophy of "quality is the life of the enterprise, adhere to the first-class technology, first-class quality, first-class cost and first-class brand", provide all-round services and solutions for customers at home and abroad, and create a better future.

ISO90001 Blended Polyester Resin , Powder Paint Polyester Resin 25Kg For Heat Transfer 0ISO90001 Blended Polyester Resin , Powder Paint Polyester Resin 25Kg For Heat Transfer 1

ISO90001 Blended Polyester Resin , Powder Paint Polyester Resin 25Kg For Heat Transfer 2
