Chromium Epoxy Polyester Coating OHSMS18001 In Various Colors

Basic Information
Place of Origin: CHINA
Brand Name: KINTE
Certification: ROHS,ISO90001,ISO14001,OHSMS18001,Reach,Qualicoat
Minimum Order Quantity: 100KG
Price: negotiate
Packaging Details: with double PP bags,N.W 20(25)kg/carton,1000KG/pallet
Delivery Time: within 10 working days
Payment Terms: L/C, D/P, T/T, D/A
Supply Ability: 500tons/month
Application: Fitness Equipment, Furniture And Cars Etc. Color: All Kinds Of Metallic Colors
Shelf Life: 12 Month Within 30℃, Avoid Direct Sunlight. Transportation: Non-dangerous Goods. It Can Be Transported In Various Ways, But It Should Be Away From Direct Sunlight, Moisture, Heat And Chemicals.
Highlight:

OHSMS18001epoxy polyester coating

,

Chromium epoxy polyester coating

,

Chromium polyester powder paint

Chromium 560 High gloss NANO dry plating Chrome mirror candy color bonding metallic Powder Coating



Introduction:



This series of products is by using the advanced Bonding technology equipment to produce surface layer metal powder coating with more bright optical effect, better metalic luster, high utilization of reclaimed powder, high powder spraying rate and the coating that without the defects such as black spots, yin and yang color and fingerprints.



Advantage:



--- The metallic pigment can be better melt with the bottom powder and will not jam the spray gun while spraying.

--- Strong adhesion between the metal powder and the base material. The powder is hard to fall off while spraying.

--- Good compatibility for the the spraying effect between recovery powder coating and new powder.

--- The metallic powder is hard to fall off and be oxided and there is no fingerprint problem.

--Colorful decorative effect is shining since containing metallic pigments like copper and golden powder, silver and aluminum powder, pearlescent pigments

--Gloss of chrome effect is above 500-560°,Just like a mirror.



Property:



Density: 1.2~1.8g/cm3( Ingredient and color demand)

Particle Size: Purpose demands, standard granularity is 35-40 um, <10um powder <10%, >100um powder <0.5%.

Storage stability: Bonding Metallic Powder Coatings should be stored below 35°C in a dry and well ventilated place away from source of heat, ignition and direct sunlight. If stored in an air-conditioner room, in order to avoid damp again, before using the powder, the powder should be kept at the room temperature or at the same temperature with the spray equipment. Under such condition, the powder can be stored stably for 12 months.

Extended, retest will be required. If the testing result meets the requirement, the powder can still be used.

Note: For the low temperature curing powder with the gloss below 40%(60°),the better stored temperature is below 30℃.



Film Characteristics:



Properties Method Value
Appearance Visual A variety of coating effects
Impact GB/T 1732-1993 1Kg*50cm
Flexibility GB/T 6742-1986 ∮2mm
Cupping Test GB/T 9753-1988 ≥6mm
Adhesion GB/T 9286-1998 0Grade
Hardness GB/T 6739-2006 >H
Salt Spray GB/T 1771-2007 ≥500h
Humility GB/T 1740-2007 ≥1000h
Film property above may decreases slightly while the gloss decreases.
Spraying This series of products is suitable for the following spraying methods: corona electrostatic spraying, friction electrostatic spraying, electrostatic fluidized bed spraying,fluidized bed thermal spraying and other spraying methods(For the last 3 methods, please requested in advance)
Film thickness :40~150μm, theoretically 50~80μm.
Curing Guide 200 ℃ / 10 mins is suggested, and also 160℃/20mins ,180 ℃ / 10 mins etc can be designed according to user’s needs.







Chromium Epoxy Polyester Coating OHSMS18001 In Various Colors 0







Chromium Epoxy Polyester Coating OHSMS18001 In Various Colors 1



Chromium Epoxy Polyester Coating OHSMS18001 In Various Colors 2



Chromium Epoxy Polyester Coating OHSMS18001 In Various Colors 3



Chromium Epoxy Polyester Coating OHSMS18001 In Various Colors 4



Chromium Epoxy Polyester Coating OHSMS18001 In Various Colors 5



Chromium Epoxy Polyester Coating OHSMS18001 In Various Colors 6
