PANTON Color Thermoset Powder Epoxy Polyester Resin For Outdoor Architecture

Basic Information
Place of Origin: CHINA
Brand Name: KINTE
Certification: ROHS,ISO90001,ISO14001,OHSMS18001,Reach
Minimum Order Quantity: 100KG
Price: negotiate
Packaging Details: with double PP bags,N.W 20(25)kg/carton,1000KG/pallet
Delivery Time: within 10 working days
Payment Terms: L/C, D/P, T/T, D/A
Supply Ability: 500tons/month
Application: Outdoor Lamps,Courtyard Leisure Facilities,Building Materials: Aluminum Ceiling And Profil Color: RAL,PANTON And Customized
Shelf Life: 12 Month Within 30℃, Avoid Direct Sunlight. Transportation: Non-dangerous Goods. It Can Be Transported In Various Ways, But It Should Be Away From Direct Sunlight, Moisture, Heat And Chemicals.
Highlight:

Thermoset Powder Polyester Resin

,

PANTON Powder Polyester Resin

,

PANTON Matt Powder Coating

Matt Powder Coating for outdoor Architecture Aluminum profile





This series of products is one kind of thermoset powder coating made of polyesterresins and acrylic resins.





Advantage:

---Gloss can be 2-5%(60°),which is please to eyes

---Good flowing, good appearance with smooth surface

---Suitable for long-term outdoor use

---Good adhesion and impact resistance

---Good over baking resistance

---Low cost and reasonable price



Property:



Density: 1.4~1.8g/cm3(Owing to the different formula and different colors)



Particle size:

Different purposes varies, the standard for the average particle size is 35 ~ 40um,smaller than 10um< 10%, greater than 100um < 0.5%



Storage stability:

Durable Matt Powder Coatings should be stored below 30°C in a dry and well ventilated place away from source of heat and direct sunlight. If stored in an air-conditioner room, in order to avoid damp again, before using the powder, the powder should be kept at the room temperature or at the same temperature with the spray equipment. Under such condition, the powder can be stored stably for 6 months. Extended, retest will be required. If the testing result meets the requirement, the powder can still be used.



Film Characteristics:

Properties Method Value
Appearance visual inspection

Various



Impact GB/T 1732-1993 ISO 6272 1Kg*50cm
Flexibility GB/T 6742-1986 ISO 1519 ∮2mm
Cupping Test GB/T 9753-1988 ISO 1520 ≥8mm
Adhesion(Cross Cut) GB/T 9286-1998 ISO 2409 0 Grade
Pencil Hardness GB/T 6739-2006 ASTM D3363 H~2H
Salt Spray GB/T 1771-2007 ISO 7253 ≥500h
Humidity GB/T 1740-2007 ISO 6270 ≥1000h
Artificial Ageing Test GB/T1865-1997 ASTM G151 1000h
All the index of film characteristics might slightly reduce with the loss of the gloss



Spraying:

This series product is suitable for the following spraying methods: corona electrostatic spraying, friction electrostatic spraying, electrostatic fluidized bed spraying, fluidized bed thermal spraying and other spraying methods(For the last 3 methods, please requested in advance)



Film thickness:40~150μm, theoretically 50~80μm.



Curing guide: 200°C/10min or customizing design,for example 180℃/15min



PANTON Color Thermoset Powder Epoxy Polyester Resin For Outdoor Architecture 0




PANTON Color Thermoset Powder Epoxy Polyester Resin For Outdoor Architecture 1
