| Place of Origin: | CHINA |
|---|---|
| Brand Name: | KINTE |
| Certification: | Qualicoat,ISO90001,ISO14000,Reach |
| Model Number: | NH3307, NH3383, NH3362 ect. |
| Minimum Order Quantity: | 500KG |
| Price: | Negotiable |
| Packaging Details: | 25kg/PE bag , 875KG/PALLET , 17,500KG/ 20GP |
| Delivery Time: | 10 working days |
| Payment Terms: | T/T, L/C, D/P |
| Supply Ability: | 80,000tons/year |
| Specification: | TGIC Cure | Application: | Powder Coating |
|---|---|---|---|
| Highlight: | 92/8 TGIC Polyester Resin,Saturated TGIC Polyester Resin,92/8 Saturated Polyester Resin |
||
Cost Effective Excellent Performance Polyester Resin Series For Tgic Cure Powder Coating
| Product | Code | Property |
| Polyester resin for TGIC powder coating 93/7 | Powder coating polyester resin NH3307 | Excellent flowability and durability, suitable for aluminum profile powder coatings |
|
Powdercoating polyester resin NH3383 |
Accelerated version of NH-3307. | |
|
Powder coating polyester resin NH3362 |
Low temperature curing resin with excellent anti-frost, weathering resistance. | |
|
Powder coating polyester resin NH3395 |
Accelerated version of NH3307, suitable for transfer printing powder coating. | |
|
Powder coating polyester resin NH3306 |
Over bake type suitable for sand textured, deep or bright color powder coatings. | |
|
Powder coating polyester resin NH3309 |
Outstanding flowability | |
| Polyester resin for TGIC powder coating 92/8 |
Powder coating polyester resin NH3295 |
Excellent flowability, suitable for clear transfer printing powder coatings |
| Polyester resin for TGIC powder coating 94/6 |
Powder coating polyester resin NH3405 |
Excellent flow, Improved version of NH3309 on weatherability |
| Polyester resin for TGIC powder coating 95:5 |
Powder coating polyester resin NH3509 |
Excellent weathering resistance |
|
Polyester resin for TGIC dry blend matt powder coatings
|
Powder coating Polyester resin NH8081 NH8588 |
Dry blend for 20~30% gloss coating. High Tg, remarkable weatherability and good storage stability. |
| Powder coating polyester resin NH8001 NH8505 | Dry blend for 25~40% gloss coating, excellent anti-yellowing, good flow and storage stability. | |
| Powder coating polyester resin NH8506 | Dry blend with NH8081 for 30%~45% gloss coating with excellent mechanical properties |
Technical Data
| Type | Ratio | Curing condition |
Acid value (mgKOH/g) |
Viscosity (mPa.s,200℃) |
Tg (℃) |
Reacting time(s) | Properties |
| NH-3307 | 93/7 | 200℃/10min | 33 | 5000 | 67 | 225 | Excellent flowability and durability |
| NH-3383 | 93/7 | 180℃/12min | 33 | 5000 | 67 | 110 | Accelerated version of NH-3307. |
| NH3362 | 93/7 | 160℃/15min | 33 | 4500 | 63 | 95 | Low temperature curing resin with excellent anti-frost, weathering resistance |
| NH3395 | 93/7 | 190℃/10min | 33 | 5000 | 67 | 150 | Accelerated version of NH3307,suitable for transfer printing powder coating. |
| NH3295 | 92/8 | 200℃/10min | 42 | 3300 | 65 | 185 | Excellent flowability ,suitable for clear transfer printing powder coatings |
| NH-3306 | 93/7 | 200℃/10min | 33 | 8000 | 69 | 140 | Over bake type suitable for sand textured, deep or bright color powder coatings. |
| NH-3309 | 93/7 | 200℃/15min | 33 | 3500 | 60 | 440 | Outstanding flowability |
| NH3309C | 93/7 | 200℃/15min | 33 | 3700 | 60 | 440 | Excellent flow, Improved version of NH3309 on weatherability |
| NH3405 | 94/6 | 200℃/10min | 30 | 6500 | 66 | 150 | Excellent weather ability resistance |
| NH-3509 | 95/5 | 200℃/15min | 22 | 8000 | 61 | 500 | Low level TGIC with excellent flow. |
| NH-8081 | 90/10 |
180℃/20min
200℃/10min |
52 | 7800 | 67 | 75 | Dry blend for 20~30% gloss coating. High Tg, remarkable weatherability and good storage stability. |
| NH-8588 | 95/5 | 22 | 7800 | 64 | 630 | ||
| NH-8001 | 90/10 |
200℃/10min |
52 | 2800 | 62 | 60 | Dry blend for 25~40% gloss coating, excellent anti-yellowing, good flow and storage stability. |
| NH-8505 | 95/5 | 22 | 6000 | 62 | 240 | ||
| NH8506 | 95/5 | 200℃/10min | 23 | 8200 | 61 | 300 | Dry blend with NH8081 for 30%~45% gloss coating with excellent mechanical properties |
Remarks:all the polyester resins could be customizes to Non-tin (A) ,anti gas burners(G),tribo gun(T) and anti-blooming(F)
