| Place of Origin: | CHINA |
|---|---|
| Brand Name: | KINTE |
| Certification: | Qualicoat,ISO90001,ISO14000,Reach |
| Model Number: | HH2782 |
| Minimum Order Quantity: | 500KG |
| Price: | Negotiable |
| Packaging Details: | 25kg/PE bag , 875KG/PALLET , 17,500KG/ 20GP |
| Delivery Time: | 10 working days |
| Payment Terms: | T/T, L/C, D/P |
| Supply Ability: | 80,000tons/year |
| Specification: | 70/30 Hybrid Cure | Application: | Indoor Epoxy Polyester Resin Powder Coating |
|---|---|---|---|
| Advantage: | Outstanding Mechanical Property,leveling,storage Stability And Chemical Resistance,TMA Free | Property: | High Gloss,and Also To Get Matt Effect |
| Ratio: | 70/30 | Curing: | 180°C/15mins |
| Highlight: | 70:30 Polyester Epoxy Resin,TMA Free Polyester Epoxy Resin,TMA Free Saturated Polyester Resin |
||
Epoxy polyester resin with high gloss and TMA free
◇ Applications:
HH2782 is a carboxyl polyester resin designed for 70/30 hybrid powder coatings.
◇ Basic features:
Outstanding mechanical properties
Good leveling
Good storage stability
Good Chemical resistance
TMA free
◇ Specifications:
Appearance: white or light yellow transparent flakes
Color(50%DMF) max:2
Acid number(mgKOH/g): 29～34
Softening point(℃): 98～112
Glass transition temp.( ℃): ～60
Melting viscosity(200℃, cone/plate, mPa·s): 6000±1000
Reactivity at 180℃(s, 30% Epoxy): 200±40
◇ Recommend Formulation: HH2782—E12
| HH2782 | E12 | Filler ＆ pigment | Leveling agent | Benzoin | 701 |
| 420 | 180 | 383 | 8 | 4 | 5 |
◇ Extrusion Condition:
Two-screw extruder
Zone I: 90～110℃ Zone II: 110～120℃
Speed of revolution: 500～1200rpm
Fineness of powder: ＜100μm
◇ Application Condition:
Electrostatic spraying with: 40～70KV
Coating film thickness: 50～100μm
Degreased cold-rolled steel 0.5mm
◇ Curing Requirement: 180℃×10~20min
◇ Film Properties:
Gel time(180℃,sec) 150~270
Horizontal flow:(180℃),mm: 22~26
Gloss(60°): ≥85%
Bending(φ1mm): pass
Adhesive(1mm,grade): 0
Pencil hardness: 1H
Impact(50cm): pass
◇ Packaging:
PE bags, N.W. 25KG±0.1KG / bag
Remarks:all the polyester resins could be customizes to Non-tin (A) ,anti gas burners(G),tribo gun(T) and anti-blooming(F)
