| Place of Origin: | CHINA |
|---|---|
| Brand Name: | KINTE |
| Certification: | ROHS,ISO90001,ISO14000,Reach,Qualicoat |
| Model Number: | NH8081&NH8506 |
| Minimum Order Quantity: | 500KG |
| Price: | Negotiable |
| Packaging Details: | 25kg/PE bag , 875KG/PALLET , 17,500KG/20GP |
| Delivery Time: | 10 working days |
| Payment Terms: | T/T, L/C, D/P |
| Supply Ability: | 80,000tons/year |
| Specification: | TGIC Cure | Application: | Powder Coating With Low Gloss Heat Transfer Finish |
|---|---|---|---|
| Advantage: | Good Leveling,weatherability,boiling Water Resistance | Property: | Good Mechanical Property,chemical Resistance,storage Stability |
| Ratio: | 90/10,95/5 | Curing Condition: | 200°C/10mins |
| High Light: | 90/10 polyester finishing resin,Dry Blend polyester finishing resin,Dry Blend powder coating polyester resin |
||
Powder Paint Polyester resin for Dry bleding Low Gloss
◇ Applications:
NH8081/NH8506 are saturated carboxyl polyester resins for low gloss polyester/TGIC powder coatings by a dry blending procedure.
◇ Basic features:
Low gloss film
Excellent mechanical properties
Good chemical resistance
Good leveling
Excellent boiling water resistance
◇ Specifications:
NH8081 NH8506
Appearance: pale yellow flake pale yellow flake
Color(50%DMF): ≤2 ≤4
Acid number(mgKOH/g) 49～55 22～25
Softening point(℃): 105～115 103～113
Glass transition temp.( ℃): ~67 ~61
Melting viscosity: 8250±1250 8100±500
(200℃, cone/plate, mPa·s)
Reactivity at 180℃(s, TGIC): 75±25 505±75
◇ Recommend Formulation:
| Formulation | NH8081 | NH8506 | TGIC | Filler ＆ pigment | Leveling agent | Benzoin |
| I | 270 | — | 30 | 200 | 3 | 1.5 |
| II | — | 270 | 14.2 | 200 | 3 | 1.5 |
◇ Extrusion Condition:
Two-screw extruder
Zone I: 90～110℃ Zone II: 110～120℃
Speed of revolution: 500～1200rpm
Fineness of powder: ＜100μm
Blend I and II in the weight ratio of 1:1 before grinding.
◇ Application Condition:
Electrostatic spraying with: 40～70KV
Coating film thickness: 50～70μm
Degreased cold-rolled steel 0.5mm
◇ Curing Requirement: 200℃×10min
◇ Film Properties:
Gloss(60°): ≤45%
Bending(φ2mm): Pass
Adhesive(1mm,grade): 0
Pencil hardness: ≥H
Impact (50cm): pass
◇ Packaging:
PE bags, N.W. 25KG±0.1KG / bag
Remarks:all the polyester resins could be customizes to Non-tin (A) ,anti gas burners(G),tribo gun(T) and anti-blooming(F)
Kinte is the first manufacturer in China to research and produce prepainted coating and it's spraying equipments.
Continuous fast production speed can reach 80m/min which surpasses the same kind of Euramerican with 40m/min. Our technology ranks tops in China and is in advanced level all over the world.
We adhere to the quality concept of "quality is the life of the enterprise", and comprehensively provide customers with one-stop solutions of standards, technical diagnosis and service. Product quality and stability are respected by customers. Kinte powder and liquid coating were successively rated as "famous brand products of Guangdong Province".
