| Place of Origin: | China |
|---|---|
| Brand Name: | KINTE |
| Certification: | ISO14000, ISO90001, Reach, Qualicoat, ROHS |
| Model Number: | HH2582AT |
| Minimum Order Quantity: | 1000kg |
| Price: | Negotiable |
| Packaging Details: | 25Kg/PE Bag, 875Kg/Pallet, 17,500Kg/20GP |
| Delivery Time: | 10 working days |
| Payment Terms: | L/C, D/P, T/T |
| Supply Ability: | 80,000 tons per year |
| Cure System: | 50/50 Polyester/Epoxy | Cure Condition: | 200℃×10min Or 180℃×15min |
|---|---|---|---|
| Acid Value (mgKOH/g): | 65-75 | Viscosity (mPa·s/200℃): | 2800±1000 |
| Softening Point(℃): | 98～108 | Glass Transition Temp.(℃): | ～ 59 |
| Properties: | Excellent Mechanical Properties And Outstanding Chemical Resistance | Application: | Suitable For Friction Gun Spraying |
| Highlight: | Friction Gun Spraying Polyester Epoxy Resin,50/50 Polyester Epoxy Resin |
||
50/50 Polyester Epoxy Resin with Excellent Mechanical Properties
◎Introduction
HH2582AT is a saturated polyester resin, which is the friction gun version of HH2582A. It is mainly used for a 50/50 polyester/epoxy mixed powder coating system and is suitable for friction gun spraying.
The working principle of friction gun spraying is to use frictional electrification to charge the powder. The charge is generated by the collision, friction, contact, and clutching between the powder and the special polymer material and nylon in the gun wall. The driving force is airflow.
There are many advantages of friction gun spraying:
1. High powder application rate for the first time, reducing recycled powder and providing benefits.
2. Overcome the Faraday cage effect, especially effective for spraying complex workpieces.
3. The powder on the workpiece is more uniform, and the surface leveling and smoothness of the coating film are better.
4. Comprehensive automatic spraying can be used to reduce labor costs.
◎Basic Features
Suitable for friction gun spraying
Excellent mechanical properties
Outstanding chemical resistance
Good leveling
Good storage stability
◎Recommend Formulation:
| HH2582AT | E-12 | Filler ＆ Pigment | Leveling agent | Benzoin | 701 |
| 300 | 300 | 383 | 8 | 4 | 5 |
◎Specifications I:
| Appearance | White or pale yellow transparent flakes |
| Acid Number (mgKOH/g) | 65～75 |
| Softening Point (℃) | 98～108 |
| Glass Transition Temp. (℃) | ～59 |
| Melting Viscosity (200℃, cone/plate, mPa·s) | 2800±1000 |
| Reactivity at 180℃ (s, 50% E-12) | 200±40 |
| Curing Requirement | 200℃×10min or 180℃×15min |
| Packaging | PE Bags, Net Weight 25kg ± 0.1kg / bag |
◎Specifications II:
| Extrusion Condition | Two-screw Extruder | |
| Jacket temperature | 110～120℃ | |
| Speed of Revolution | 500～1200rpm | |
| Fineness of Powder | ＜100μm | |
| Application Condition | Electrostatic Spraying With | 40～70KV |
| Coating Film Thickness | 50～70μm | |
| Degreased Cold-rolled Steel | 0.5mm | |
| Film Properties | Gel Time (180℃, sec) | 200~320 |
| Horizontal Flow (180℃, mm) | 26~30 | |
| Gloss (60°) | ≥90% | |
| Bending (φ1mm) | Pass | |
| Adhesive (1mm, grade) | 0 | |
| Pencil Hardness | ≥1H | |
| Impact (50cm) | Pass | |
◎Remarks:
All the polyester resins could be customized to Non-tin (A), anti-gas burners (G), tribo gun (T), and anti-blooming (F).
