| Place of Origin: | China |
|---|---|
| Brand Name: | KINTE |
| Certification: | ISO14000, ISO90001, Reach, Qualicoat, ROHS |
| Model Number: | HH2533 |
| Minimum Order Quantity: | 1000kg |
| Price: | Negotiable |
| Packaging Details: | 25Kg/PE Bag, 875Kg/Pallet, 17,500Kg/20GP |
| Delivery Time: | 10 working days |
| Payment Terms: | L/C, D/P, T/T |
| Supply Ability: | 80,000 tons per year |
| Cured Type: | 50/50 Polyester Epoxy | Cured Requirement: | 130℃×15-20min |
|---|---|---|---|
| Acid Number (mgKOH/g): | 68-75 | Viscosity (mPa·s/200℃): | 2500±1000 |
| Softening Point(℃): | 93～118 | Glass Transition Temp.(℃): | ～ 54 |
| Properties: | Low Curing Temperature | Application: | For MDF Powder Coatings |
| Highlight: | Low Curing Powder Coating Polyester Resin,MDF Powder Coating Polyester Resin |
||
Low Curing Powder Coating Polyester Resin for MDF Powder Coatings
◎Introduction
HH2533 is a saturated polyester resin, which is mainly used for 50/50 polyester epoxy mixed powder coating and can be realized low temperature curing at 130℃.
Powder coatings have developed rapidly in recent years. Compared with traditional liquid coatings, powder coatings have the characteristics of energy-saving, environmental protection, and excellent comprehensive performance. With the strengthening of the concept of energy-saving and environmental protection, the development of low-temperature curing polyester resin is a development trend. In addition, some heat-sensitive substrates (such as medium density fiberboard) are also sensitive to temperature and require low-temperature curing.
Reducing the curing temperature will inevitably require the resin to have high reactivity, and high reactivity will have a certain impact on the performance of the coating. The existing powder coating system mainly has the following problems when it is used for low-temperature curing. On the one hand, the system reactivity is not enough, the powder coating cannot be completely cured, and the coating performance is not ideal; In order to achieve the reactivity required for low-temperature curing, polyester resins often have high melt viscosity, high reactivity, and cannot be fully leveled under low-temperature conditions. These all greatly affect the decorative properties of powder coatings.
HH2533 greatly improves the reactivity, and at the same time has good storage stability. When the resin is applied to powder coatings, it achieves low-temperature curing very well, the coating has good adhesion to the substrate, and has good leveling and stability. Chemical resistance, ideal for MDF powder coatings.
◎Basic Features
Low curing temperature
Excellent storage stability
Excellent chemical resistance.
Outstanding mechanical performance
◎Recommend Formulation:
| HH2533 | E-12 | Filler ＆ Pigment | Leveling agent | Benzoin | 701 |
| 300 | 300 | 383 | 8 | 4 | 5 |
◎Specifications I:
| Appearance | White or pale yellow transparent flakes |
| Acid Value (mgKOH/g) | 68～75 |
| Softening Point (℃) | 93～118 |
| Glass Transition Temp. (℃) | ～54 |
| Melting Viscosity (200℃, ICI, mPa·s) | 2500±1000 |
| Reactivity at 180℃ (s, 50% E-12) | 70±40 |
| Curing Requirement | 130℃×15-20min |
| Packaging | PE Bags, Net Weight 25kg ± 0.1kg / bag |
◎Specifications II:
| Extrusion Condition | Two-screw Extruder | |
|
Jacket temperature |
110～120℃ | |
| Speed of Revolution | 500～1200rpm | |
| Fineness of Powder | ＜100μm | |
| Application Condition | Electrostatic Spraying With | 40～70KV |
| Coating Film Thickness | 50～70μm | |
| Degreased Cold-rolled Steel | 0.5mm | |
| Film Properties | Gel Time (180℃, sec) | 30~120 |
| Horizontal Flow (180℃, mm) | 18~22 | |
| Gloss (60°) | ≥85% | |
| Bending (φ1mm) | Pass | |
| Adhesive (1mm, grade) | 0 | |
| Pencil Hardness | ≥1H | |
| Impact (50cm) | Pass | |
◎Remarks:
All the polyester resins could be customized to Non-tin (A), anti-gas burners (G), tribo gun (T), and anti-blooming (F).
