| Place of Origin: | China |
|---|---|
| Brand Name: | KINTE |
| Certification: | ISO14000, ISO90001, Reach, Qualicoat, ROHS |
| Model Number: | NH0307G-1 |
| Minimum Order Quantity: | 1000kg |
| Price: | Negotiable |
| Packaging Details: | 25Kg/PE Bag, 875Kg/Pallet, 17,500Kg/20GP |
| Delivery Time: | 10 working days |
| Payment Terms: | L/C, D/P, T/T |
| Supply Ability: | 80,000 tons per year |
| Curing Type: | 93/7 Polyester TGIC Or 95/5 Polyester HAA | Curing Requirement: | 200℃×10min (TGIC) Or 180℃×10min (HAA) |
|---|---|---|---|
| Acid Value (mgKOH/g): | 30-36 | Melting Viscosity (mPa·s/200℃): | 3200±800 |
| Softening Point: | 105～115℃ | Glass Transition Temperature: | ～ 63℃ |
| Properties: | High Cost-performance | Application: | Recommended For Sand And Wrinkle Powder Coatings |
| Highlight: | Slow Curing TGIC Polyester Resin,Wrinkle Powder Coating TGIC Polyester Resin |
||
Slow Curing TGIC Polyester Resin for Sand and Wrinkle Powder Coatings
◎Introduction
NH0307G-1 is a saturated polyester resin used in polyester / TGIC powder coating
system and polyester / HAA powder coating system.
Models with a G indicate powder coatings made with this polyester resin that is suitable for direct fired furnace curing.
The heating method of the circulating gas stream can be direct heating or indirect heating. The so-called direct heating method is that the fuel is burned in the open flame in the circulating air duct, which belongs to the open fire heating. The generated high-temperature flue gas is mixed with the circulating air flow and enters the jet box in the furnace under the action of the circulating fan, and the coating is cured through the nozzle. The advantages of the direct-fired furnace curing method are that the furnace heating time is fast and the temperature control accuracy is high.
◎Basic Features
Slow curing version of NH0307, suitable for direct fired furnace curing
High cost-effective
Excellent storage stability
Recommended for sand and wrinkle powder coatings
◎Recommend Formulation:
NH0307G-1/TGIC
| NH0307G-1 | TGIC | Filler ＆ pigment | Leveling agent | Benzoin | 701 | 703 |
| 300 | 22.6 | 190 | 4 | 2 | 2.5 | / |
NH0307G-1/HAA
| NH0307G-1 | T-105 | Filler ＆ pigment | Leveling agent | Benzoin | 701 | 703 |
| 300 | 15.8 | 190 | 4 | 2 | 2 | 2 |
◎Specifications:
| Appearance | white or pale yellow transparent flakes |
| Acid Value (mgKOH/g) | 30～36 |
| Softening Point (℃) | 105～115 |
| Glass Transition Temp. (℃) | ～63 |
| Melting Viscosity (200℃, ICI, mPa·s) | 3200±800 |
| Reactivity at 180℃ (s, 7% TGIC) | 320±80 |
| Curing Requirement |
200℃×10min (TGIC) 180℃×10min (HAA) |
| Packaging | PE Bags, Net Weight 25kg ± 0.1kg / bag |
◎Specifications II:
| Extrusion Condition | Two-screw Extruder | |
| Jacket temperature | 100～110℃ | |
| Speed of Revolution | 500～1200rpm | |
| Fineness of Powder | ＜100μm | |
| Application Condition | Electrostatic Spraying With | 40～70KV |
| Coating Film Thickness | 60～80μm | |
| Degreased Cold-rolled Steel | 0.5mm | |
| Film Properties | Gel Time (180℃, sec) | 300~600 |
| Horizontal Flow (180℃, mm) | 26~30 | |
| Gloss (60°) | ≥80% | |
| Adhesive (1mm, grade) | 0 | |
| Pencil Hardness | ≥1H | |
| Impact (50cm) | Pass | |
◎Remarks:
All the polyester resins could be customized to Non-tin (A), anti gas burners (G), tribo gun (T) and anti-blooming (F).
◎Company Profile:
Kinte Materials Science and Technology Co., Ltd. is subordinate to China Machinery Industry Corporation (a key state-owned enterprise directly managed by SASAC, ranking 284 among the world's top 500 in 2021). It is a national high-tech enterprise under China National Electric Apparatus Research Institute Co., Ltd. (Stock Code: 688128), a listed enterprise on the SSE STAR MARKET. Focusing on the R & D, production, and sales of environmentally friendly coatings (powder coatings, waterborne industrial coatings) and powder coating resins, the company is committed to improving the global market competitiveness of China's environmentally friendly coating industry. Now it has become the leader and promoter in China’s technological development of environmentally friendly coatings as well as polyester resins for powder coatings!
In 2017, the new production base with 80000 tons annual capacity was put into construction in Dongguan, Guangdong, and the annual production capacity reached 120000 tons by the end of 2020, opening the road to global diversified development.
