| Place of Origin: | China |
|---|---|
| Brand Name: | KINTE |
| Certification: | ROHS, ISO90001, ISO14000, Reach, Qualicoat |
| Model Number: | NH6688 |
| Minimum Order Quantity: | 1000kg |
| Price: | Negotiable |
| Packaging Details: | 25Kg/PE Bag, 875Kg/Pallet, 17,500Kg/20GP |
| Delivery Time: | 10 working days |
| Payment Terms: | L/C, D/P, T/T |
| Supply Ability: | 80,000 tons per year |
| Curing Ratio: | 96/4 HAA Curing Type | Curing Requirement: | 180℃×15min |
|---|---|---|---|
| Acid Value (mgKOH/g): | 19-24 | Viscosity (200℃, MPa·s): | 5600±800 |
| Softening Point: | 100～110℃ | Glass Transition Temp.( ℃): | ～58℃ |
| Properties: | Low Gloss Film And Excellent Mechanical Properties | Application: | For Low Gloss Primid Powder Coatings By Dry Blending Procedure |
| Highlight: | Dry Blended Polyester Resin,96/4 HAA Blended Polyester Resin |
||
96/4 HAA Blended Polyester Resin for Low Gloss Powder Coatings
◎Introduction
NH6688 are saturated carboxyl polyester resins for low gloss polyester/primid (96:4) powder coatings by dry blending procedure.
Conventional matte powder coatings are matted by adding a matting curing agent to the powder to achieve a matting effect during the curing process, which reduces the quality of the powder because there is a low-temperature kneading process during the powder production process, resulting in the formation of impurities before the powder is cured.
Dry mixed matting powder coatings are made of fast and slow (high, low acid value) two components of the powder, through the two powders in accordance with the 1:1 mixture of homogeneous, stable coating gloss, boiling resistance, and greatly improve the weatherability and mechanical properties of the coating, as well as storage stability.
At the same time, the dry mixing matting method avoids the addition of matting agent in the production process, which further reduces the cost of powder coatings.
◎Basic Features
Low gloss film
Excellent mechanical properties
Good leveling, good storage stability
Good chemical resistance, fine anti-yellowing
◎Recommend Formulation:
| Formulation | NH6381 | NH6688 | T-105 | Filler ＆ pigment | Leveling agent | Benzion |
| I | 200 | — | 15 | 150 | 2.4 | 1.2 |
| II | — | 200 | 7.5 | 150 | 2.4 | 1.2 |
◎Specifications:
| Appearance | Pale yellow flakes |
| Color (50% DMF) | ≤3 |
| Acid Value (mgKOH/g) | 19～24 |
| Softening Point (℃) | 100～110 |
| Glass Transition Temp. (℃) | ～58 |
| Melting Viscosity (200℃, cone/plate, mPa·s) |
5600±800 |
| Reactivity at 180℃ (s, 4% XL552) |
250±30 |
| Curing Requirement | 180℃×15min |
| Packaging | PE Bags, Net Weight 25kg ± 0.1kg / bag |
◎Specifications II
| Extrusion Condition | Two-screw Extruder | |
|
Zone I: 90～110℃ |
Zone II: 110～120℃ |
|
| Speed of Revolution | 500～1200rpm | |
| Fineness of Powder | ＜100μm | |
|
Blending Extrudate I and II with weight ratio 1:1 before grinding. |
||
| Application Condition | Electrostatic Spraying With | 40～70KV |
| Coating Film Thickness | 50～80μm | |
| Degreased Cold-rolled Steel | 0.5mm | |
| Film Properties | Gloss (60°) |
≤40% |
|
Bending (φ2mm) |
Pass |
|
|
Adhesive (1mm, grade) |
0 | |
| Pencil Hardness | ≥1H | |
|
Direct Impact Resistance |
Pass 50kg·cm |
|
◎Remarks:
All the polyester resins could be customized to Non-tin (A), anti gas burners (G), tribo gun (T) and anti-blooming (F).
