| Place of Origin: | China |
|---|---|
| Brand Name: | KINTE |
| Certification: | ISO14000, ISO90001, Reach, Qualicoat, ROHS |
| Model Number: | NH6161 & NH6687 |
| Minimum Order Quantity: | 1000kg |
| Price: | Negotiable |
| Packaging Details: | 25Kg/PE Bag, 875Kg/Pallet, 17,500Kg/20GP |
| Delivery Time: | 10 working days |
| Payment Terms: | L/C, D/P, D/A, T/T |
| Supply Ability: | 80,000 tons per year |
| Product Type: | Dry Blending Polyester Resins | Ratio: | 90/10 & 96/4 |
|---|---|---|---|
| Cured Type: | Polyester/HAA Curing System | Cured Time: | 160℃×15min |
| Acid Number (mgKOH/g): | 68～76 & 24～29 | Glass Transition Temp.( ℃): | ~58 & ~56 |
| Properties: | Low Temperature Cure And Low Gloss | Application: | For Outdoor Semi-gloss Powder Coatings |
| Highlight: | Low Cure Blended Polyester Resin,Low Gloss Blended Polyester Resin |
||
Low Cure Blended Polyester Resin for Low Gloss Outdoor HAA Powder Coatings
◎Introduction
NH6161 and NH6687 are high and low acid value polyester resins respectively, which are used in polyester/primid (HAA) powder coating systems. Using NH6161 and NH6687 to make powder respectively and then dry mixing to make outdoor semi-gloss powder coating.
At present, powder coatings for outdoor use are usually cured with TGIC. However, due to the physiological toxicity of TGIC, it has been banned by the European Union and other places. Therefore, the use of environmentally friendly and non-toxic HAA to replace TGIC has become the trend in the powder coating industry.
With the change in people's aesthetic concept and the problem of light pollution caused by high-gloss coatings, matte powder coatings that can produce soft surface effects are more and more widely used.
Dry-blending matting method is a commonly used method for preparing matte powder coatings. This method uses different polyesters with large differences in reactivity during the curing process. Due to the difference in reactivity, the coating surface produces a microscopically rough surface to achieve a matting effect. , the gloss of 18-45 can be obtained without adding a matting aid, and the overall cost is low.
At present, the curing temperature of polyester for dry-blended matt powder coating of the HAA system is generally 180℃, and a higher curing temperature means more energy consumption. Studies have shown that for every 10°C drop in the curing temperature of the coating, about 10% of the energy can be saved.
And NH6161 and NH6687 can achieve 160 ℃ low-temperature curing so that the application field of powder coatings has been further expanded.
◎Basic Features
Low temperature curing
Llow coating gloss
Good weather resistance and leveling
Excellent mechanical properties
Good water resistance
◎Recommend Formulation:
| Formulation | NH6161 | NH6687 |
XL-552 |
Pigments & Fillers | Leveling Aegnt | Benzoin |
| I | 200 | — | 22.2 | 150 | 2.4 | 1.2 |
| II | — | 200 | 8.3 | 150 | 2.4 |
1.2 |
◎Specifications I
| Items | NH6161 | NH6687 |
| Appearance | Pale yellow flake | Pale yellow flake |
| Acid Number (mgKOH/g) | 68～76 | 24～29 |
| Softening Point (℃) | 100～115 | 100～115 |
| Glass Transition Temp. (℃) | ～58 | ～56 |
| Melting Viscosity (ICI, mPa·s) | 3500±1000 | 5200±1200 |
| Reactivity s (180℃, 10,5% T105) | 90±40 | 210±80 |
| Curing Requirement | 160℃×15min | |
| Packaging | PE Bags, Net Weight 25kg ± 0.1kg / bag | |
◎Specifications II
| Extrusion Condition | Two-screw Extruder | 110～120℃ |
| Speed of Revolution | 500～1200rpm | |
| Fineness of Powder | ＜100μm | |
| Extrude NH6161 and NH6687 respectively according to the formula, and mix and pulverize in a ratio of 1:1 to make powder. | ||
| Application Condition | Electrostatic Spraying With | 40～70KV |
| Coating Film Thickness | 50～70μm | |
| Degreased Cold-rolled Steel | 0.5mm | |
| Film Properties | Gloss (60°) |
≤38% |
| Bending (φ1mm) | Pass | |
| Adhesive (1mm, grade) | 0 | |
| Pencil Hardness | ≥1H | |
| Impact (50cm) | Pass | |
◎More Code
| Code | Ratio | Cure Cycle | Acid Value (mgKOH/g) | Viscosity (mPa.s/200℃) | Tg (℃) | Reactivity (s/180℃) | Properties |
| NH6083 | 90/10 | 180℃*10min | 80~90 | 1500~3500 | ~58 | 30-90 | Fast cure resin. For one shot matt formulations. |
| NH6685 | 96/4 | 180℃*10min | 19~24 | 4800~6400 | ~57 | 220-280 | |
| NH6381 | 93/7 | 180℃*10min | 47~54 | 3800~4800 | ~60 | 60-120 | Dry-blended for low gloss powder coatings with good mechanical properties and flow. |
| NH6688 | 96/4 | 180℃*15min | 19~24 | 4800~6400 | ~56 | 220-280 | |
| NH6161 | 91/9 | 160℃*15min | 68~76 | 2500~4500 | ~59 | 50-150 | Low bake resins. Dry-blended for low gloss powder coatings, with good mechanical properties and flow. |
| NH6687 | 96/4 | 160℃*15min | 24~29 | 4000~6500 | ~56 | 160-260 |
◎Remarks: All the polyester resins could be customized to Non-tin (A), anti gas burners (G), tribo gun (T) and anti-blooming (F).
