| Place of Origin: | China |
|---|---|
| Brand Name: | KINTE |
| Certification: | ISO14000, ISO90001, Reach, Qualicoat, ROHS |
| Model Number: | HH2682 |
| Minimum Order Quantity: | 1000kg |
| Price: | Negotiable |
| Packaging Details: | 25Kg/PE Bag, 875Kg/Pallet, 17,500Kg/20GP |
| Delivery Time: | 10 working days |
| Payment Terms: | L/C, D/P, D/A, T/T |
| Supply Ability: | 80,000 tons per year |
| Features: | High Tg, Excellent Flow And Good Mechanical Properties | Cured System: | 60:40 Polyester/Epoxy Type |
|---|---|---|---|
| Cured Condition: | 180℃/10min | Acid Number (mgKOH/g): | 53-57 |
| Viscosity (mPa·s/200℃): | 2500～4500 | Softening Point(℃): | 95～105 |
| Glass Transition Temp.(℃): | ～ 56 | Applications: | For 60/40 Polyester/epoxy Hybrid Powder Coating |
| Highlight: | 60/40 Polyester Epoxy Resin,Indoor Powder Coating Polyester Epoxy Resin |
||
Excellent Flow 60/40 Polyester Epoxy Resin for Indoor Use Powder Coatings
◎Introduction
HH2682 is a carboxyl polyester resin designed for 60/40 hybrid powder coatings.
Fast-curing polyester often helps in the following aspects in the use of powder coatings.
For example:
(1) Increase the crosslinking density, thereby improving the mechanical properties of the coating film such as hardness, cross-cut adhesion, and impact resistance;
(2) Reduce the curing temperature or shorten the curing time to achieve low-temperature curing or rapid curing;
(3) Hinder the melting and leveling of the powder, and achieve the control of the size of the texture and the appearance of the three-dimensional sense;
(4) Interfere with the slow or medium-speed curing system, and reduce the apparent gloss while leveling.
◎Basic Features
Fast curing
Good leveling
Good mechanical properties
Good storage stability
◎Recommend Formulation:
| HH2682 | E12 | Filler ＆ Pigment | Leveling Agent | Benzoin | 701 |
| 360 | 240 | 383 | 8 | 4 | 5 |
◎Specifications I
| Appearance | White or Light Yellow Transparent Flakes |
|
Color (50% DMF) |
max:3 |
| Acid Number (mgKOH/g) | 53～57 |
| Softening Point (℃) | 95～105 |
| Glass Transition Temp. ( ℃) | ～56 |
| Melting Viscosity (ICI, mPa·s/200℃) | 2500～4500 |
| Reactivity at 180℃ (s, 50% Epoxy) | 100～200 |
| Curing Requirement | 180℃/10min |
| Packaging | PE Bags, Net Weight 25kg ± 0.1kg / bag |
◇Extrusion Condition:
Two-screw Extruder
Zone I: 90～110℃ Zone II: 110～120℃
Speed of Revolution: 500～1200rpm
Fineness of Powder: ＜100μm
◇Application Condition:
Electrostatic spraying with: 40～70KV
Coating film thickness: 50～70μm
Degreased cold-rolled steel: 0.5mm
◇Film Properties:
| Gel Time (180℃, sec) | 100~200 |
| Horizontal Flow (180℃, mm) | 26~29 |
| Gloss (60°) | ≥90% |
| Bending (φ1mm) | Pass |
| Adhesive (1mm, grade) | 0 |
| Pencil Hardness | ≥1H |
| Impact (direct, reserve) |
Pass 50kg·cm |
◎More Code
| Code | Ratio | Cure Cycle | AV (mgKOH/g) | Viscosity (mPa.s/200℃) | Tg (℃) | Reactivity (s/180℃) | Properties |
| HH2683 | 60/40 | 180℃*15min | 47~55 | 2500~3500 | ~54 | 90-150 | General purpose resin with good flow, good chemical resistance and mechanical properties. |
| HH2683B | 60/40 | 180℃*15min | 47~55 | 2500~3500 | ~54 | 120-180 | Non-tin version of HH2683. |
| HH2685 | 60/40 | 180℃*20min | 47~55 | 2500~3500 | ~58 | 200-300 | Excellent flow, high gloss. Suitable for alloy wheel-hub powder coatings. |
| HH2686 | 60/40 | 200℃*10min | 52.5~57 | 3000~4500 | ~55 | 170-300 | Economic general purpose resin. Excellent flow, good matting performance. |
| HH2608 | 60/40 | 200℃*15min | 50~60 | 2500~4500 | ~55 | 250-450 | Outstanding flow, high gloss, excellent mechanical properties. |
| HH2686P | 60/40 | 200℃*10min | 50~60 | 2500~4500 | ~55 | 240-360 | General purpose resin. Excellent flow and strong anti-interference ability. Good balance of properties. Suitable for matt powder coatings. |
| HH2687 | 60/40 | 200℃*10min | 51~66 | 3000~5000 | ~60 | 200-300 | High Tg, excellent flow, good mechanical properties. |
◎Remarks: All the polyester resins could be customized to Non-tin (A), anti gas burners (G), tribo gun (T) and anti-blooming (F).
