| Place of Origin: | China |
|---|---|
| Brand Name: | KINTE |
| Certification: | ISO14000, ISO90001, Reach, Qualicoat, ROHS |
| Model Number: | HH2506 |
| Minimum Order Quantity: | 1000kg |
| Price: | Negotiable |
| Packaging Details: | 25Kg/PE Bag, 875Kg/Pallet, 17,500Kg/20GP |
| Delivery Time: | 10 working days |
| Payment Terms: | L/C, D/P, D/A, T/T |
| Supply Ability: | 80,000 tons per year |
| Features: | Tin Free | Cure Type: | 50/50 Polyester Epoxy |
|---|---|---|---|
| Cure Requirement: | 200℃×10min | Acid Number (mgKOH/g): | 65-75 |
| Viscosity (mPa·s/200℃): | 3000-6000 | Reactivity: | 250-450 |
| Glass Transition Temp.(℃): | ～ 58 | Applications: | Hybrid Powder Coatings |
| Highlight: | Tin Free Saturated Polyester Resin,Saturated Polyester Resin Low Gloss |
||
50/50 Tin Free Saturated Polyester Resin for Hybrid Low Gloss Powder Coatings
Introduction
HH2506 is 50/50 curing polyester, mainly used in polyester/epoxy powder coating systems.
Basic Features
Organotin Free
Specially used for matt powder coatings
Good appearance, mechanical properties, and storage stability.
Recommend Formulation:
HH2506/014U
| HH2506 | 014U Epoxy | PM228 | Leveling agent | Benzoin | 701 | PE 520 | carbon black | 3390 |
| 150 | 150 | 158 | 5 | 2 | 3 | 3 | 4 | 25 |
Specifications I
| Appearance | White or Light Yellow Transparent Flakes |
| Acid Number (mgKOH/g) | 65～75 |
| Glass Transition Temp. ( ℃) | ~ 58 |
| Melting Viscosity (ICI, mPa·s/200℃) |
3000-6000 |
| Reactivity at 180℃ (s, 50% 014U) |
250-450 |
| Curing Requirement |
200℃×10min |
| Packaging | PE Bags, Net Weight 25kg ± 0.1kg / bag |
Specifications II:
| Extrusion Condition | Two-screw Extruder | |
|
Jacket Temperature |
110～120℃ | |
| Speed of Revolution | 500～1200rpm | |
| Fineness of Powder | ＜100μm | |
| Application Condition | Electrostatic Spraying With | 40～70KV |
| Coating Film Thickness | 50～70μm | |
| Degreased Cold-rolled Steel | 0.5mm | |
| Film Properties | Gel Time (180℃, sec) | 450~180 |
| Horizontal Flow (180℃, mm) | 20~25 | |
| Gloss (60°) |
≤10% |
|
| Blending (φ1mm) | Pass | |
| Adhesive (1mm, grade) | 0 | |
| Pencil Hardness | ≥1H | |
| Impact (50cm) |
+50/-40
|
|
Remarks: All the polyester resins could be customized to Non-tin (A), anti gas burners (G), tribo gun (T) and anti-blooming (F).
