| Place of Origin: | CHINA |
|---|---|
| Brand Name: | KINTE |
| Certification: | ISO90001,ISO14000 |
| Model Number: | NO |
| Minimum Order Quantity: | 100KG |
| Price: | negotiate |
| Packaging Details: | 20kg/box |
| Delivery Time: | within 10 working days |
| Payment Terms: | L/C, D/P, T/T, D/A |
| Supply Ability: | 500tons/month |
| Application: | Furniture | Color: | Beige ,white , Black |
|---|---|---|---|
| Property: | Environmental Friendly | Cure Condition: | 140℃/20min |
| Advantage: | Excellent Mechanical Properties And Chemical Resistance | ||
| High Light: | thermoset MDF Powder Coatings,140C MDF Powder Coatings,140C thermoset powder coating |
||
MDF Powder coating for Medium Density Fiber Board on furniture environmental friendly
MDF powder coating is a durable thermosetting coating finish that fully encapsulates the MDF board with excellent mechanical properties and chemical performance.
Recommended Application
For MDF furniture and hardware finishes, such as commercial furniture, residential furniture, retail displays, office fitouts, kitchen and bath cabinets, etc.
Key features
Technical Data
| Test Items | Test Methods | Value | |
| Impact | ISO 6272 | GB/T 1732-1993 | 50kg.cm |
| Cupping test | ISO 1520 | GB/T 9753-1988 | 5mm |
| Adhesion | ISO 2409 | GB/T 9286-1998 | 0 grade |
| Flexibility | ISO 1519 | GB/T 6742-1986 | 2mm |
| Pencil hardness | ASTM D3363 | GB/T 6739-1996 | ≥2H |
| Salt spray | ISO 7253 | GB/T 1771-1991 | ≥500h |
| Humidity | ISO 6270 | GB/T 1740-1979 | ≥500h |
| Acetone |
Rub the coating 10 times with 1kg force, the coating isn’t eroded |
||
| Methyl ethy ketone |
Rub the coating 10 times with 1kg force, the coating isn’t eroded |
||
| Vapour | The coating would not foaming in 2 hours | ||
| Heat resistance | Put an article with 180℃ on the coating for 20 minutes, the coating appearance do not change obviously | ||
Properties
Color: According to customers requirements
Appearance: Sand texture
Density: 1.2-1.7 (This data would change by the color difference)
Gloss: 5-40% (60°)
Application reference
Spaying method: electrostatic spaying
Timber treatment: polish and clean the surface according to the actual requirement
Timber moisture content: 4%-8%
Pre-heat temperature: the substrate temperature is about 60℃
Curing condition: Circulated heating by infrared and hot air. 130 ℃ ~ 150 ℃ (surface temperature of the substrate), 5 ~ 20 minutes, according to the production line.Our current client uses the condition at 140 ℃/8min
Notes
suitable for outdoor or indoor use
Spraying effect is affected evidently by the different kind of MDF substrate
The color and appearance would not affected by spraying thickness
Laboratory panel is different from factory panel. It need to adjust the spraying reference
Transportation and storage
20kg/carton
It is not hazardous article, so it has no specific transportation requirement
Store in dry and cool place under 25℃
The shelf-life is 6 month within 25℃ in dry and cool condition.
Health and safety :
Please refer to the MSDS.
