| Place of Origin: | China |
|---|---|
| Brand Name: | KINTE |
| Certification: | ISO14000, ISO90001, Reach, Qualicoat, ROHS |
| Model Number: | HH2585G |
| Minimum Order Quantity: | 1000kg |
| Price: | Negotiable |
| Packaging Details: | 25Kg/PE Bag, 875Kg/Pallet, 17,500Kg/20GP |
| Delivery Time: | 10 working days |
| Payment Terms: | L/C, D/P, D/A, T/T |
| Supply Ability: | 80,000 tons per year |
| Features: | Excellent Mechanical Properties | Cured System: | 50:50 Polyester/Epoxy Type |
|---|---|---|---|
| Cured Condition: | 180℃/15min | Acid Number (mgKOH/g): | 69-76 |
| Viscosity (mPa·s/200℃): | 2000～3500 | Softening Point(℃): | 95～110 |
| Glass Transition Temp.(℃): | ～ 59 | Applications: | For 50/50 Polyester/epoxy Hybrid Powder Coating |
| Highlight: | 50/50 Saturated Polyester Epoxy Resin,Mechanical Properties Polyester Epoxy Resin |
||
50/50 Saturated Polyester Epoxy Resin With Excellent Mechanical Properties for Hybrid Powder Coatings
◎Introduction
HH2583G is a saturated polyester resin, mainly used for 50/50 polyester/epoxy hybrid powder coatings systems.
◎Basic Features
Good leveling
Excellent mechanical properties
Good storage stability
Excellent chemical resistance
◎Recommend Formulation:
| HH2585G | E12 | Filler ＆ Pigment | Leveling Agent | Benzoin | 701 |
| 300 | 300 | 383 | 8 | 4 | 5 |
◎Specifications I
| Appearance | White or Light Yellow Transparent Flakes |
| Acid Number (mgKOH/g) | 69～76 |
| Softening Point (℃) | 95～110 |
| Glass Transition Temp. ( ℃) | ～59 |
| Melting Viscosity (ICI, mPa·s/200℃) | 2000～3500 |
| Reactivity at 180℃ (s, 50% E-12) | 100～200 |
| Curing Requirement | 180℃/15min |
| Packaging | PE Bags, Net Weight 25kg ± 0.1kg / bag |
◇Extrusion Condition:
Two-screw Extruder
Jacket Temperature: 110～120℃
Speed of Revolution: 500～1200rpm
Fineness of Powder: ＜100μm
◇Application Condition:
Electrostatic spraying with: 40～70KV
Coating film thickness: 50～70μm
Degreased cold-rolled steel: 0.5mm
◇Film Properties:
| Gel Time (180℃, sec) | 100~250 |
| Horizontal Flow (180℃, mm) | 27~30 |
| Gloss (60°) | ≥90% |
| Bending (φ1mm) | Pass |
| Adhesive (1mm, grade) | 0 |
| Pencil Hardness | ≥1H |
| Impact (50cm) |
Pass |
◎More Code
| Code | Ratio | Cure Cycle | AV (mgKOH/g) | Viscosity (mPa.s/200℃) | Tg (℃) | Reactivity (s/180℃) | Properties |
| HH2581 | 50/50 | 180℃*10min | 67~75 | 2000~3500 | ~55 | 100-200 | For fast cure formulation. Excellent flow and good mechanical properties. |
| HH2582 | 50/50 | 180℃*15min | 67~75 | 2000~3000 | ~59 | 150-250 | Good flow and heat resistance, high gloss, excellent chemical resistance. Suitable for metallic powder coatings. |
| HH2582A | 50/50 | 180℃/15min or 200℃/10min | 65~75 | 1800~3800 | ~54 | 200-320 | The tin-free version of HH2582A |
| HH2583 | 50/50 | 180℃*15min | 67~75 | 3500~5500 | ~55 | 150-250 | Suitable for low gloss powder coatings. Good flow and film fineness, excellent mechanical properties. |
| HH2585 | 50/50 | 180℃*15min | 67~75 | 2000~3500 | ~57 | 100-200 | Economic resin. Suitable for heat transfer print powder coatings with good mechanical properties. |
| HH2586 | 50/50 | 180℃*15min | 68~80 | 5000~8500 | ~60 | 120-200 | Fast cure, excellent flexibility and impact resistance. |
◎Remarks: All the polyester resins could be customized to Non-tin (A), anti gas burners (G), tribo gun (T) and anti-blooming (F).
